Product Details
Place of Origin: China Foshan
Brand Name: Available for ODM
Certification: CE
Model Number: DJT10-20
Document: Product Brochure PDF
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Contact Us
Packaging Details: Carton packaging，1 units per carton
Delivery Time: 3-8 work days
Payment Terms: T/T
Supply Ability: 5000
Applicable Industries: |
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Other |
Mounting: |
Wall Fan |
After-sales Service Provided: |
Online Support |
Place Of Origin: |
China Foshan |
Customized Support: |
OEM |
Blade Material: |
Plastic |
Voltage: |
220V |
Warranty: |
1 Year |
Product Type: |
Exhaust Fan |
Model Number: |
DJT10-20 |
Applicable Industries: |
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction Works , Energy & Mining, Other |
Mounting: |
Wall Fan |
After-sales Service Provided: |
Online Support |
Place Of Origin: |
China Foshan |
Customized Support: |
OEM |
Blade Material: |
Plastic |
Voltage: |
220V |
Warranty: |
1 Year |
Product Type: |
Exhaust Fan |
Model Number: |
DJT10-20 |
Product Usage
On ships, diagonal flow fans provide a comfortable living and working environment for the crew. They can remove exhaust gas and moisture in the cabin to ensure fresh air. Even in harsh marine environments, diagonal flow fans can operate stably to ensure the safe navigation of ships.
Product wind wheel
The design of the wind wheel of the diagonal flow fan has high safety. The material of the wind wheel has been strictly selected and has good fire and explosion resistance. During operation, the wind wheel can work stably without any safety hazards such as loosening or falling off. In addition, the design of the wind wheel also takes into account the coordination with the fan casing to ensure the overall safety of the fan.
Easy to install
Diagonal flow fans can also adapt well to some special installation environments. For example, in renovation projects, installation is difficult due to space limitations or the influence of the original structure. However, diagonal flow fans can be flexibly adjusted according to actual conditions to meet the needs of different installation conditions. Its adjustable installation angle and position provide installers with more options.
Product Parameters
| Model number | Power | Airflow | Static Pressure | Noise Level | Duct Diameter | Quantity per Carton | Net Weight |
| (W) | (m5/h) | (Pa) | (dB) | (mm) | (Unit／Box) | (kg) | |
| DJT10-20 | 30/26 | 200/170 | 183/130 | 30/25 | 100 | 6 | 1.8 |
| DJT15-54 | 48/40 | 540/384 | 330/280 | 40/35 | 150 | 6 | 2.2 |
| DJT20-90 | 76/60 | 900/820 | 380/310 | 50/45 | 200 | 6 | 2.7 |
| DJT25-170 | 173/152 | 1700/1200 | 550/480 | 56/50 | 250 | 1 | 18 |
| DJT31-230 | 350/260 | 2300/1900 | 650/500 | 60/55 | 315 | 1 | 20 |
Product Dimensions
Product size parameters
| Model number | A | B(Φ) | C | D | E | F | H | H1 |
| dJT10-20 | 300 | 100 | 100 | 214 | 62 | 60 | 182 | 95 |
| DJT15-54 | 293 | 150 | 120 | 237 | 72 | 70 | 211 | 110 |
| DJT20-90 | 304 | 200 | 140 | 258 | 78 | 85 | 235 | 124 |
| DJT25-170 | 367 | 250 | 317 | 208 | 120 | 95 | 365 | 196 |
| DJT31-230 | 450 | 315 | 360 | 255 | 120 | 95 | 410 | 215 |
